REGUPOL playfix FXG

Product details

Our single layer safety tile is a successful compromise between long-term durability and cost efficiency. Maximum fall height is two metres.

The REGUPOL playfix FXG safety tile is the more cost-effective version of our REGUPOL playfix safety tiles. The material composition is simpler as these safety tiles are made of granulate and have a single layer structure. REGUPOL playfix FXG is designed for fall heights of up to 2 metres. It has slightly lower toughness and resilience levels than the REGUPOL playfix FX safety tile, but still offers our well-known REGUPOL safety, while reducing costs.

REGUPOL playfix FXG

Colour and pattern selection

Features


  • Acoustics
  • Safety
  • Certified high-quality production
  • Sustainable
  • Hygiene
  • Cannot be dispersed through play
  • Water permeable
  • Resistant to de-icing salt
  • Certified
  • Weather-resistant
  • Can be cleaned
  • Slip-resistant
  • Fast installation

Technical Specifications


Material

PUR binder, components made of synthetic rubber (coloured)

Structure

Single-layer structure with a studded underside for drainage and elasticity; central dummy joint on the top side, edges with dowel holes

Dimensions / Weight / Maximum fall height

1,000 x 500 x 50 mm | approx. 34 kg/m² / 1.50 m
1,000 x 500 x 70 mm | approx. 46 kg/m² / 2.00 m

Tolerances: Length/width +/- 1% | thickness +/- 2mm

Maximum fall height

1.5 to 2 m, depending on overall safety tile thickness,
Fall protection testing in acc. with DIN EN 1177

Installation

On concrete, asphalt or compacted bed of crushed stone / gravel

Accessories

Plug-in dowels, one-component adhesive

Please note:
The MVVTB (Model Administrative Provisions – Technical Building Rules) and entry 50 of the REACH Annex XVII contain requirements products and floor surfaces have to meet. Please check to make sure that your intended application for our products conforms with these requirements.

Services

Online spatial simulation, Product sample service, Tender text/specification, individual consulting worldwide, internal quality certificates, On-site quality and function testing, Line marking and lettering application, Inlays and prints, Customized product development and design, Private labelling
Cleaning and maintenance, Repairs, re-topping and renovation, Equipment and accessories, External certification

Country-specific requirements must be complied with. We will be happy to advise you regarding the product you want to buy.

Olaf Brinkmann

Your contact at REGUPOL

We're here to help.

Olaf Brinkmann
REGUPOL Germany GmbH & Co. KG
Sales Manager International

REGUPOL playfix FXG: single-layer; practical and good

Our single-layer safety tile with cost benefits is made of homogenous material. The studs on the underside facilitate drainage, provide elasticity and allow cable routing underneath the tiles. The edges have dowel holes to enable the tiles to be connected together securely. The appropriate dowels for the REGUPOL playfix safety tiles can also be obtained from us.
